HORZ420


Horai Granulator Screen

Model: Z420


• Made from highest quality US Steel: Mild, Stainless and Plate

• Manufactured to exceed OEM specifications

• Custom screen hole shapes are available in: Circles, Squares, Hexagons and Octagons

• Screen hole sizes are available: 3/32 inch through 3 inches

• Metric hole sizes also available in millimeters or centimeters







Horai Granulator Replacement Screens

These are the standard hole sizes however we custom manufacture these screens any hole size into any screens, within reason.

Part #: HORZ420-14-L            Holes: 1/4 inches

Part #: HORZ420-516-L            Holes: 5/16 inches

Part #: HORZ420-38-L            Holes: 3/8 inches

Part #: HORZ420-12-L            Holes: 1/2 inches

Part #: HORZ420-58-L            Holes: 5/8 inches

Part #: HORZ420-34-L            Holes: 3/4 inches

Part #: HORZ420-KU-6-L            Holes: 6 millimeters

Part #: HORZ420-KU-8-L            Holes: 8 millimeters

Part #: HORZ420-KU-10-L            Holes: 10 millimeters

Part #: HORZ420-KU-12-L            Holes: 12 millimeters

Part #: HORZ420-KU-16-L            Holes: 16 millimeters

Part #: HORZ420-KU-20-L

These are the standard hole sizes however we custom manufacture these screens any hole size into any screens, within reason.

Granulator Screen Size

Part Length: 17.250 inches

Part Width: 10.500 inches

Part Thickness: 0.313 inches

Arc Depth: 4.613 inches
