CUMB1828


Cumberland Granulator Screen

Model: B1828


• Made from highest quality US Steel: Mild, Stainless and Plate

• Manufactured to exceed OEM specifications

• Custom screen hole shapes are available in: Circles, Squares, Hexagons and Octagons

• Screen hole sizes are available: 3/32 inch through 3 inch

• Metric hole sizes also available in millimeters or centimeters







Cumberland Granulator Replacement Screens

Part #: CUMB1828-332            Holes: 3/32 inches

Part #: CUMB1828-18              Holes: 1/8 inches

Part #: CUMB1828-532            Holes: 5/32 inches

Part #: CUMB1828-316            Holes: 3/16 inches

Part #: CUMB1828-732            Holes: 7/32 inches

Part #: CUMB1828-14              Holes: 1/4 inches

Part #: CUMB1828-516            Holes: 5/16 inches

Part #: CUMB1828-38              Holes: 3/8 inches

Part #: CUMB1828-12              Holes: 1/2 inches

Part #: CUMB1828-58              Holes: 5/8 inches

Part #: CUMB1828-34              Holes: 3/4 inches

Part #: CUMB1828-78              Holes: 7/8 inches

Part #: CUMB1828-1                Holes: 1 inches

Part #: CUMB1828-2                Holes: 2 inches

Part #: CUMB1828-3                Holes: 3 inches

Granulator Screen Size

Part Length: 28.280 inches

Part Width: 17.000 inches

Part Thickness: 0.675 inches

Arc Depth: 4.470 inches
