B&JMD812CG


Ball & Jewell Granulator Screen

Model: MD812CG


• Made from highest quality US Steel: Mild, Stainless and Plate

• Manufactured to exceed OEM specifications

• Custom screen hole shapes are available in: Circles, Squares, Hexagons and Octagons

• Screen hole sizes are available: 3/32 inch through 3 inches

• Metric hole sizes also available in millimeters or centimeters







Ball & Jewell Granulator Replacement Screens

Part #: B&JMD812CG-332-K            Holes: 3/32 inches

Part #: B&JMD812CG-18-K              Holes: 1/8 inches

Part #: B&JMD812CG-532-K            Holes: 5/32 inches

Part #: B&JMD812CG-316-K            Holes: 3/16 inches

Part #: B&JMD812CG-732-K            Holes: 7/32 inches

Part #: B&JMD812CG-14-K              Holes: 1/4 inches

Part #: B&JMD812CG-516-K            Holes: 5/16 inches

Part #: B&JMD812CG-38-K              Holes: 3/8 inches

Granulator Screen Size

Part Length: 11.970 inches

Part Width: 8.003 inches

Part Thickness: 0.250 inches

Arc Depth: 2.780 inches
